Eco-Worthy 16KWh Home Backup Solar Power Bundle With 48V 314Ah LiFePO4 Lithium Battery and 6000W 48V All-in-One Off Grid Inverter

48V 314Ah Lithium Battery

Battery Capacity: 314Ah	Battery Power: 16.08kWh
Rated Voltage: 51.2V	Voltage Range: 40~58.4V
Maximum Charge/ Discharge Current: 200A	Charge Temperature Range: 0-55℃
Disharge Temperature Range:﹣20－55℃	Maximum Charge Voltage: 58.4V
Battery Weight: 293.2lb/133kg	Battery Size:  32.56*20.47*9.92in/80.7*52*25.2cm
Circuit Breaker:2*125A(250A)	Max. parallel number:15pcs
BMS Brand：PACE BMS



6000W 48V Pure Sine Wave Power Inverter

Inverter output
Rated pover: 6000VA/6000W	Parallel capability: Yes,6 units maximwm
AC voltage regulationl (battery mode): 230VAC+5% @5060Hz	Surge power: 12000VA
Efficiency (peak): 93%	Waveform: Pure sine wawe
Transfer time: 10ms typical, 20mns Max
Solar Charge
Maximum PV array power: 8000W	MPPT range @ operating voltage: 120VDC~450VDC
Number of independent MPP trackers/strings per MPp tracker: 2/1	Max.input current per MPP tracker: 16A
Maximum Py array opencircuit voltage: 500VDC	Maximum solar charge current: 100A
AC Charging Mode
Charge current: 80A	AC input voltage: 230VAC
Selectable voltage range: 170-280 VAC (For personal computers);90-280 VAC (For home appliances)	Frequency range: 50Hz/60Hz (Auto sensing)
Physica
Protection degree: IP20	Dimension (W/H/D)：460/395/132mm
Net weight: 13.5kg
Operating environment
Humidity: 5% to 95% Relative humidity (Non-condensing)	Altitude: <2000m
Operating temperature: 0C- 55°C	Storage temperature: -15°C-60°C

Package included:

1 x 6kW 48V All-in-one Inverter
1 x 51.2v 314ah battery
1 x 51.2v 314ah battery manual
1 x Battery to Inverter communication cable(1500mm)
1 Group Of Wall-mounted Bracket
1 Pair Of Battery to Busbarcable(2AWG 1500mm Black)
